Fiber G657A2

The bending insensitive single-mode optical fiber G.657.A2, is available in 200 μm & 245 μm diameters. Since dedicated high-performance acrylic composites are used for coating protection, the fiber still has outstanding bending loss characteristics while reducing the size. Small size optical fiber can save a lot of space occupancy of pipeline and increase the core capacity of cable, which is the best choice for pipeline network.

Send Inquiry

Description

Technical Parameters

our company

30+ years

Our factory was found in 1992, first start with coaxial cable which was one of the biggest manufacturers in lin'an city.In year of 2001 started focusing on the production of optical cables.

30+ countries

In year of 2008, set up international sales department and sale optical fiber cable to more than 30 countries and have 18 years` rich experience to export cables .

Features

Good bending loss characteristics, less bending loss.
Smaller fiber sizes of 200 μm are available, and the design cross-sectional area of the cable is reduced by more than 30%.

Application Scenarios

• High density metropolitan area network and narrow space access network
• Blowing tiny cables
• FTTx

own brand

FTTH drop cable-Ink printing

Flat cable-Plasma pringting

Outdoor cable GYTC8S-Iron printing

Jumper cable- SC/UPC-SC/APC

GYTC8S 24 core -wooden drum

FTTH cable-1km drum

FTTH cable-carton packing

Patch cords-Pallet package

Pack and ship

Patch cords in Pallet delivery

FTTH cable in cartons packing

Flat cable in plywood drum package

Composite drum full loaded into contianer

Solid wooden drum loading photo

Hot Tags: fiber g657a2, China fiber g657a2 manufacturers, suppliers, factory

Technical Characteristics

Parameter	Conditions	Units	Value
Optical
Attenuation	1310nm	dB/km	≤ 0.350
	1383nm	dB/km	≤ 0.350
	1550nm	dB/km	≤ 0.210
	1625nm	dB/km	≤ 0.230
Attenuation vs. Wavelength	1310nm VS. 1285- 1330nm	dB/km	≤ 0.05
Attenuation vs. Wavelength	1550nm VS. 1525- 1575nm	dB/km	≤ 0.04
Zero Dispersion Wavelength	-	nm	1300 - 1324
Zero Dispersion Slope	-	ps/(nm2·km)	≤ 0.092
Dispersion	1550nm	ps/(nm·km)	13.3 - 18.6
Dispersion	1625nm	ps/(nm·km)	17.2 - 23.7
Polarization Mode Dispersion	-	ps/√km	≤ 0.2
Cut-off Wavelength λcc-Cable	-	nm	≤ 1260
Mode Field Diameter (MFD)	1310nm	μm	8.6±0.4
Mode Field Diameter (MFD)	1550nm	μm	9.6±0.5

Attenuation Discontinuity	1310nm	dB	≤ 0.03
	1550nm	dB	≤ 0.05
Geometrical
Cladding Diameter		μm	125±0.7
Cladding Non-Circularity		%	≤ 0.8
Core/Cladding Concentricity Error		μm	≤ 0.5
Coating Diameter (Uncolored)		μm	235-255	190-210
Coating/Cladding Concentricity Error		μm	≤ 12.5	≤ 10
Curl		m	≥ 4
Environmental (1550nm, 1625nm)
Temperature Cycling	-60℃ to +85℃	dB/km	≤ 0.05
High Temperature & High Humidity	85℃, 85% RH, 30days	dB/km	≤ 0.05
Water Immersion	23℃, 30days	dB/km	≤ 0.05
High Temperature Aging	85℃, 30days	dB/km	≤ 0.05
Mechanical
Proof Stress	-	GPa	0.69
		kpsi	100
Coating Strip Force *	Peak	N	1.3 - 8.9
	Average	N	1.0 - 5.0
Tensile Strength	Fk=50%	GPa	≥ 4.00
	Fk= 15%	GPa	≥ 3.20
Dynamic Fatigue (Nd)	-	-	≥ 20
Macrobending Loss
Ø30 mm×10 t	1550nm	dB	≤ 0.03
	1625nm	dB	≤ 0. 1
Ø20 mm×1 t	1550nm	dB	≤ 0. 1
	1625nm	dB	≤ 0.2
Ø15 mm×1 t	1550nm	dB	≤ 0.4
	1625nm	dB	≤ 0.8
* When the coating diameter is 200±10, the peak peeling force of the coating is 0.6-8.9N, and the average is 0.6-5.0N.
