Fiber G652D

G.652.D single-mode optical fiber is designed for transmission systems covering the entire wavelength range of 1260 to 1625nm. This single-mode fiber effectively mitigates water peak losses associated with hydrogen and hydroxide ion absorption near 1383nm, extending the operational window into the E-band (1360 to 1460 nm) and thereby increasing the spectral bandwidth by approximately 100 nm. The G.652.D single-mode optical fiber comprehensively optimizes attenuation and dispersion performance across the entire wavelength range of 1260 to 1625nm, meeting the demands for high-speed, multi-channel transmission on a single fiber. Therefore, the G.652.D single-mode optical fiber stands out as one of the best choices for constructing networks.

Send Inquiry

Description

Technical Parameters

our company

30+ years

Our factory was found in 1992, first start with coaxial cable which was one of the biggest manufacturers in lin'an city.In year of 2001 started focusing on the production of optical cables.

30+ countries

In year of 2008, set up international sales department and sale optical fiber cable to more than 30 countries and have 18 years` rich experience to export cables .

Application

The G.652.D single-mode optical fiber is not only widely used for voice transmission, data, video, and other services, providing customers with high-cost performance and quality products, but it also extensively serves major telecommunications carriers. It is suitable for building backbone networks, local networks, access networks, and large enterprise networks.

Characteristics

• Lower water peak value

• Exhibits lower PMD (Polarization Mode Dispersion) values

• Operates within an extended wavelength range to the E-band

• Suitable for low-cost coarse wavelength division multiplexing (CWDM) systems

• Supports upgrades from CWDM to dense wavelength division multiplexing (DWDM) systems

• Precise control of geometric dimensions, resulting in low fusion splice losses

• Excellent coating protection with superior stripping performance

own brand

FTTH drop cable-Ink printing

Flat cable-Plasma pringting

Outdoor cable GYTC8S-Iron printing

Jumper cable- SC/UPC-SC/APC

GYTC8S 24 core -wooden drum

FTTH cable-1km drum

FTTH cable-carton packing

Patch cords-Pallet package

Pack and ship

Patch cords in Pallet delivery

FTTH cable in cartons packing

Flat cable in plywood drum package

Composite drum full loaded into contianer

Solid wooden drum loading photo

Hot Tags: fiber g652d, China fiber g652d manufacturers, suppliers, factory

Technical Characteristics

Features	Conditions	Value	Unit
Optical Requirements
Attenuation	1310 nm	≤0.34	dB/km
	1383 nm	≤0.32	dB/km
	1550 nm	≤0.20	dB/km
	1625 nm	≤0.22	dB/km
Dispersion Coefficient	1550 nm	≤ 18	ps/(nm ·km)
Dispersion Coefficient	1625 nm	≤22	ps/(nm ·km)
Zero Dispersion Wavelength	-	1300~ 1324	nm
Zero Dispersion Slope	-	≤0.092	ps/(nm2 ·km)
PMD Link Design Value(M=20,Q=0.01%) Typical Value	-	≤0.1 ≤0.06 0.04	ps/ km ps/ km ps/ km
Cable Cutoff Wavelength (λcc)	-	≤ 1260	nm
Mode Field Diameter (MFD)	1310 nm	9.2±0.4	μm
Mode Field Diameter (MFD)	1550 nm	10.4±0.5	μm
E仟ective Group Index Of Refraction (Ne仟)	1310 nm	1.4683	-
E仟ective Group Index Of Refraction (Ne仟)	1550 nm	1.4688	-
Point Discontinuities	1310 nm	≤0.05	dB
Point Discontinuities	1550 nm	≤0.05	dB
Geometrical Requirements
Cladding Diameter	-	125±0.7	μm
Cladding Non-Circularity	-	≤ 1.0	%
Coating Diameter	-	245±10	μm
Coating-Cladding Concentricity Error	-	≤ 10.0	μm
Core-Cladding Concentricity Error	-	≤0.6	μm
Curl (radius)	-	≥4.0	m
Environmental Requirements(1310nm & 1550nm & 1625nm)
Temperature Dependence	-60 ℃~+85 ℃	≤0.05	dB/km
Temperature-Humidity Cycling	-10 ℃~+85 ℃ , 98% RH	≤0.05	dB/km
Water-Soaked Dependence	23 ℃ , for 30 days	≤0.05	dB/km
Damp Heat Dependence	85 ℃ and 85% RH, for 30 days	≤0.05	dB/km
Dry Heat	85 ℃ , for 30 days	≤0.05	dB/km
Mechanical Requirements
Proof Test	-	≥9.0	N
Macro-Bend induced Attenuation 100 turns Ф 60 mm	1550 nm	≤0.1	dB
Macro-Bend induced Attenuation 100 turns Ф 60 mm	1625 nm	≤0.1	dB
Coating Strip Force	Typical Average Force	1.0~5.0	N
Coating Strip Force	Peak Force	1.3~8.9	N
Dynamic Stress Corrosion Susceptibility Parameter (Nd)	-	≥20	-
Delivery Length	2.1~75.6		km/reel
