Single Mode Fiber G657A1

Single Mode Fiber G657A1

G.657.A1, the bending insensitive single-mode optical fiber, not only has good bending resistance, but also has good compatibility with G.652.D. At the same time, it can extend the coverage of the access network and is the best product for optical fiber access.
Send Inquiry

Description

Technical Parameters

our company





company
30+ years
Our factory was found in 1992, first start with coaxial cable which was one of the biggest manufacturers in lin'an city.In year of 2001 started focusing on the production of optical cables.
30+ countries
In year of 2008, set up international sales department and sale optical fiber cable to more than 30 countries and have 18 years` rich experience to export cables .



Features


  • Low loss & bending insensitive
    Two optional diameters: 245 μm
    Optimized MFD and precise geometric properties
    Good compatibility with G.652.D single-mode fiber



Application Scenarios





• Gigabit broadband home & FTTP
• 5G pre-network construction
• Big data center & computer interconnection





own brand





FTTH drop cable-Ink printing
FTTH drop cable-Ink printing
Flat cable-Plasma pringting
Flat cable-Plasma pringting
Outdoor cable GYTC8S-Iron printing
Outdoor cable GYTC8S-Iron printing
Jumper cable- SC/UPC-SC/APC
Jumper cable- SC/UPC-SC/APC
GYTC8S 24 core -wooden drum
GYTC8S 24 core -wooden drum
FTTH cable-1km drum
FTTH cable-1km drum
FTTH cable-carton packing
FTTH cable-carton packing
Patch cords-Pallet package
Patch cords-Pallet package





Pack and ship


Patch cords in Pallet delivery
Patch cords in Pallet delivery
FTTH cable in cartons packing
FTTH cable in cartons packing
Flat cable in plywood drum package
Flat cable in plywood drum package
4b86f9a7e7a1b777db558f0849be4352
Composite drum full loaded into contianer
eedd5e3aac661809b4fc7f60d27f57d8
Solid wooden drum loading photo


Tips

What`s the different of G.657.A1 and G.657.A2 ?

ITU-T G.657.A1 and G.657.A2 specify single-mode optical fibers designed specifically for bend-insensitive applications. Network engineers rely on these fibers for fiber-to-the-home (FTTH) deployments (overview). Tight bend radii can lead to macrobending attenuation in standard fiber deployments and high-density cabling.

Here is a direct comparison of their specifications and use cases.

1. Minimum Bending Radius
G.657.A1: 10mm minimum bend radius. This specification allows installers to pass cables through standard residential corners and distribution boxes without signal loss. It provides a reliable benchmark for most FTTH drop cable deployments.

G.657.A2: 7.5mm minimum bend radius. Manufacturers use advanced refractive index analysis to achieve tighter tolerances, such as trench-assisted core design. This prevents light from escaping the core at sharp angles, making A2 fiber ideal for ultra-high-density patch panels.

2. Optical Stability under Physical Stress
Both fibers use a standard 125 µm quartz glass cladding. They have the same physical breaking strength. However, their optical stability differs when subjected to physical stress.

G.657.A1: Maintains acceptable insertion loss during standard handling and cabling. Highly reliable for static installations, the cable remains stable after deployment.

G.657.A2: Provides superior optical stability at sharp bends. Ensures consistent data transmission even if the cable is accidentally squeezed, pulled, or coiled within a crowded server rack.

3. Deployment Scenarios

G.657.A1: Standard FTTH drop cables and outdoor distribution networks. Engineers specify A1 when cabling from street distribution boxes to the exterior of buildings. It balances bending tolerances with cost-effectiveness.

G.657.A2: Indoor fiber optic networks, data centers, and multi-residential units (MDUs). The 7.5 mm bend radius allows installers to cable under floors, along floorboards, and around 90-degree sharp corners without degrading the optical signal.

4. Cost and Manufacturing
G.657.A2 fiber optics are more expensive than... The manufacturing processes for G.657.A1 and A2 require complex core doping to achieve their stringent bend insensitivity. Purchasing managers should specify A1 for long, straight runs to control budgets, and reserve A2 for space-constrained, compact interior environments.

5. G.652.D Backward Compatibility
G.657.A1 and G.657.A2 are fully backward compatible with the ITU-T G.652.D single-mode fiber standard. They share the matched mode field diameter (MFD). Technicians can directly fusion splice G.657 fiber to conventional G.652.D external equipment cables without incurring high splice losses or requiring specialized equipment.






Hot Tags: single mode fiber g657a1, China single mode fiber g657a1 manufacturers, suppliers, factory

Technical Characteristics







Parameter

conditions

Units

value

Optical

Attenuation

1310nm

dB/km

≤ 0.350

1383nm

dB/km

≤ 0.350

1550nm

dB/km

≤ 0.210

1625nm

dB/km

≤ 0.230

Attenuation vs. Wavelength

1310nm VS.

1285-1330nm

dB/km

≤ 0.04

1550nm VS.

1525-1575nm

dB/km

≤ 0.03

Zero Dispersion Wavelength

-

nm

1300 - 1324

Zero Dispersion Slope

ps/(nm2·km)

≤ 0.092

Polarization Mode Dispersion

-

ps/√km

≤ 0.2

Cut-off Wavelength λcc(Cable)

-

nm

≤ 1260

Mode Field Diameter (MFD)

1310nm

μm

9.2±0.4

1550nm

μm

10.4±0.5

Attenuation Discontinuity

1310nm

dB

≤ 0.03





1550nm

dB

≤ 0.05

Geometrical

Cladding Diameter

μm

125±0.7

Cladding Non-Circularity

%

≤ 1.0

Core/Cladding Concentricity Error

μm

≤ 0.5

Coating Diameter (Uncolored)

μm

245±10

Coating/Cladding Concentricity Error

μm

≤12

Curl

m

≥ 4

Environmental (1550nm, 1625nm)

Temperature Cycling

-60℃ to +85℃

dB/km

≤ 0.05

High Temperature & High Humidity

85℃, 85% RH, 30days

dB/km

≤ 0.05

Water Immersion

23℃, 30days

dB/km

≤ 0.05

High Temperature Aging

85℃, 30days

dB/km

≤ 0.05

Mechanical

Proof Stress

-

GPa

0.69

kpsi

100

Coating Strip Force *

Peak

N

1.3 - 8.9

Average

N

1.0 - 5.0

Tensile Strength

Fk=50%

GPa

≥ 4.00

Fk=15%

GPa

≥ 3.20

Dynamic Fatigue (Nd)

-

-

≥ 20

Macrobending Loss

Ø30mm×10t

1550nm

dB

≤ 0.25

1625nm

dB

≤ 1.0

Ø20mm×1t

1550nm

dB

≤ 0.75

1625nm

dB

≤ 1.5

* The peak peel force of the coating is 0.6-8.9N, and the average value is 0.6-5.0N when the coating diameter is 200±10.
